The 1756SC-CTR8 is a counter Input Module that is manufactured by Spectrum Control. The 1756SC-CTR8 features under the 1756 ControlLogix series and comes with 8 single ended counter input types. The module operates at a counter speed of 0 to 65 Hertz and has an isolation voltage of 2550 Volts DC. The 1756SC-CTR8 also features an input frequency of 1 to 65 Hertz with an input impedance of 24 kOhms. The module features a backplane current of 230 mA at

The 1756-WS weigh scale module is made by Hardy Solutions and designed to be installed in the Allen Bradley ControlLogix PLC chassis. The 1756-WS scale module is a single weigh scale module and it reads the diagnostic data and weight from a set of strain gauge sensors or load cells and it transfers this data over the chassis backplane to the central ControlLogix processor. The 1756-WS module digitizes and conditions the weight signals and transmits the gross weight, net weight,

The Allen Bradley 1756-TIME is a ControlLogix time synchronization module that uses GPS technology to provide accurate time synchronization on different interfaces. The different protocols and standards for synchronization includes the Inter-range Instrumentation Group Code B (IRIG-B) standards, PTP (Precision Time Protocol) on Ethernet and the ControlLogix backplane, Network Time Protocol (NTP) over Ethernet, and ControlLogix backplane for CST (Coordinated System Time) and UTC (Coordinated Universal Time) conversion. The 1756-TIME Synchronization Module is powered through the ControlLogix backplane. Its status

The Allen Bradley 1756-TBSH provides a flexible linkage between 1756 I/O modules and plant wiring. It is an I/O module accessory that needs to be ordered separately from the module. This 20-pin spring-clamp RTB ships with a standard housing. It is part of the Bulletin 1756 Removable Terminal Block series that are plugged into the front of ControlLogix I/O modules. It is compatible with selected 1756 Series of AC Digital Inputs, AC Digital Outputs, Analog Inputs, Analog RTDs and Thermocouples,

The Allen Bradley 1756-TBS6H is a Removable Terminal Block (RTB) for 1756 I/O modules. It is an I/O module accessory and must be ordered separately. It provides flexibility in interconnecting 1756 I/O modules and industrial plant wiring. It is easily plugged into the front section of the I/O module. The 1756-TBS6H removable terminal block is a 36-pin spring-clamp with standard housing (wiring arm depth < 2.5 〖mm〗^2). It has dimensions of 5.51 x 4.41 x 5.71 in. and it weighs

The Allen Bradley 1756-TBE is an Extended-Depth Housing used when additional wire routing space in an RTB is required for applications. It is ordered separately and is a component of the Bulletin 1756 Removable Terminal Block Series that uses heavy gauge wiring. The I/O terminal block and extended-depth housing combination allows up to 628 sq. mm wire capacity. The 1756-TBE Extended-Depth Terminal Housing protects wiring connections by providing a cover to the wired RTB when it is seated on the

The Allen Bradley 1756-TBCH is a Removable Terminal Block (RTB) for 1756 I/O modules. It is an I/O module accessory and must be ordered separately. The 1756-TBCH provides flexibility in interconnecting 1756 I/O modules and industrial plant wiring. It plugs into the front of an I/O module. The 1756-TBCH removable terminal block is a 36-pin cage-clamp with standard housing (wiring arm depth of 2.5 mm. sq.). When terminating signal to the RTB, the required Torque is 0.5 Nm screw torque.
